ZX CHART is a multi-function statistical data analysis and graphing program written by James L. Hill in 1985. It accepts up to 18 named parameters and a calculated maximum number of cases, then computes descriptive statistics (high, low, mean, and standard deviation) for each parameter. The program offers seven chart types from a menu: two scattergraph modes (parameter vs. case number, and parameter vs. parameter), a frequency distribution histogram, and a bar graph showing selected cases relative to their parameter averages. Output can be sent directly to a printer via COPY or previewed on screen, and the program and its data can be saved to tape under the user-supplied data ID name.
Program Analysis
Program Structure
The program is organized into clearly separated functional blocks, each beginning at a round line number. Execution starts at line 1 (after the splash screen at line 9090) and flows through data entry, then jumps to the menu at line 2500. The major sections are:
- Lines 1–310: Initialization, dimension setup, and session header data entry (ID, number of parameters, number of cases).
- Lines 510–700: Parameter name entry loop with paged display and correction support.
- Lines 1010–1240: Data value entry loop, paged 10 rows at a time, with
-999as a missing-value sentinel. - Lines 1500–1630: Single-entry modification by parameter and case index.
- Lines 2010–2170: Statistics computation (high, low, mean, standard deviation) stored into array
D(NP,4). - Lines 2500–2630: Main menu, input routing, and “clear and reformat” confirmation.
- Lines 2700–2780: Shared subroutine for auto-copy / screen-preview mode selection.
- Lines 3000–3550: Scattergraph — parameter vs. case number, with axis-drawing subroutine at 3500.
- Lines 4000–4320: Scattergraph — parameter vs. parameter (cross-plot).
- Lines 5000–5230: Bar graph — selected cases vs. their parameter averages.
- Lines 6000–6410: Frequency distribution histogram.
- Lines 9000–9130: Save-to-tape routine and splash/title screen.
Menu Dispatch
The menu at line 2600 uses an arithmetic GOTO expression — a well-known Sinclair BASIC idiom — to branch to the correct section in a single statement:
GOTO 2610*(D$="8")+9000*(D$="7")+3000*(D$="1")+4000*(D$="2")+5000*(D$="4")+6000*(D$="3")+500*(D$="5")+1500*(D$="6")
Each Boolean sub-expression evaluates to 1 (true) or 0 (false), so only one term contributes a non-zero target. If none match, the result is 0, which causes a “line not found” error — there is no default/error path for invalid menu choices.
Array Layout
| Array | Dimensions | Contents |
|---|---|---|
P(NP,NC) | parameters × cases | Raw data values; -999 = missing |
D(NP,4) | parameters × 4 stats | 1=high, 2=low, 3=mean, 4=std dev |
N$(NP,5) | parameters × 5 chars | Parameter name (5-character fixed strings) |
G(ND,2) | divisions × 2 | Frequency count and scaled bar height |
Statistics Computation
Lines 2010–2170 iterate over all parameters and cases. The standard deviation is computed using the computational formula SQR((G*S2 - TM*TM) / (G*G)), where G is the count of valid (non-sentinel) cases, TM is the sum, and S2 is the sum of squares. This is the population standard deviation, not the sample (Bessel-corrected) version. Division is by G², equivalent to SQR(S2/G - (TM/G)²).
Missing Value Handling
The sentinel value -999 is used throughout to mark missing data. Data entry skips blanks (line 1080 uses VAL D$ only when D$<>""), but the array is initialized to zero by DIM, not to -999. This means cases never explicitly entered will be treated as zero rather than missing — a subtle bug, especially if the user advances past entries using the "A" shortcut.
Parameter Entry — Encoded ID Strings
The program uses a compact string encoding for multi-item selection lists: parameters are entered as a string like .03.07.12, and parsed with VAL Y$(Y*3-1 TO Y*3). Each group is exactly 3 characters (dot + 2-digit number), so the loop count is LEN Y$/3. This requires careful zero-padding by the user; there is no input validation on the format.
Display Techniques
Three pre-built strings are used for decorative display lines:
E$— 32 spaces, used to erase areas of the screen withPRINT AT r,c;E$O$— a 64-character row of▄(lower-half block) characters used as a visual separatorU$— a 64-character row of▀(upper-half block) characters used as a visual separator
Parameter names in N$(N) are printed character-by-character vertically on the Y axis (lines 3500–3550) using sequential PRINT AT calls for each of the five character positions.
Bar Graph Scaling (Section 5000)
The bar graph at lines 5000–5230 draws each parameter’s value relative to its mean, with bars scaled to a range of ±GR where GR = MAX(|high - mean|, |low - mean|). The bar is drawn by slicing the pre-built string G$ (a row of block characters preceded by a vertical bar) to a computed length: G$( TO 1+((P(P,M)-(D(P,3)-GR))*24/(GR*2))). This maps the value into a 0–24 character wide bar. If GR=0 (all values equal), it is set to 1 to prevent division by zero.
Frequency Distribution (Section 6000)
The histogram builds array G(ND,2) where column 1 holds raw counts and column 2 holds counts scaled to a maximum bar height of 15 rows. A special case at line 6155 ensures that values exactly at the upper boundary of the last division are counted in the last bin rather than falling through. Range labels are printed at alternating rows (line 6310: LET X=X+(X<21)-2*(X=21)) to avoid label overlap when divisions are narrow.
Save / Reload Behaviour
Line 9040 saves the program (with its live arrays) under the name stored in H$. Line 9045 then corrupts the last character of H$ by subtracting 128 from its character code — this is an artifact of the SAVE operation and leaves H$ in a modified state. On reload, line 9105 checks whether H$ equals "ZX CHART" (the default/unmodified state); if not, the saved data ID is displayed and execution resumes from the menu (GOTO MENU, where MENU=2500) rather than from the start, allowing a dataset to be loaded and immediately analysed.
Notable Anomalies
- Line 1000 is referenced by the parameter name entry loop (
GOTO 1000at line 560) but does not exist; the loop is intended to jump to the data entry section which begins at line 1010. This causes a “line not found” error if the user pressesAin the parameter name screen. - Line 1500 is referenced at line 1630 (
GOTO 1500) but does not exist; section 1510 is the actual start of the modify-entry block, causing a “line not found” error on repeated modifications. - Line 6295 uses
VAL "(D(N,2)+(D-1)*GI)"insideSTR$, which evaluates the expression at runtime via string-to-value conversion — a valid but unusual way to format a computed number as a string for display. - The
COPYcommand (lines 3250, 4280, 5217, 6380) sends the current screen to a compatible printer; this is available only with appropriate hardware attached.
